Jinan PLK Machinery Co.,Ltd is one of the most reliable manufacturers and suppliers of towable boom lift in China. Please feel free to buy high quality towable boom lift at competitive price from our factory. Contact us for more details.
Towable Boom Lift
It platform height from 8m to 16m (working height from 10m to 18m). Load capacity 200kg. It can be towed easily from site to site and work for you quickly. It is widely used for aerial working, such as road lamp repair, palm tree trimming work and cleaning the window etc.
Power options available on PLK LIFT towable boom lift include AC (connect with electricity), DC (battery power), gasoline, diesel and 'Dual-Energy' ( for example battery & diesel or battery & gasoline), combining the benefits of two power sources on the same machine.
PLK LIFT Towable boom lift is popular for its easily moving and operation. Having it will be your wisest choice.
Hot Tags: towable boom lift, China, suppliers, factory, price, Cherry Picker, Electric Boom Lift
Model | TBL-12A | TBL-14A | TBL-14A | TBL-16A | TBL-18A | TBL-20A | TBL-22A | TBL-24A |
+Telescopic | +Telescopic | +Telescopic | +Telescopic | +Telescopic | +Telescopic | |||
Lifting height | 10M | 12M | 12M | 14M | 16M | 18M | 20M | 22M |
Working height | 12M | 14M | 14M | 16M | 18M | 20M | 22M | 24M |
Load capacity | 300KG | 220KG | 300KG | 300KG | 220KG | 220KG | 220KG | 220KG |
Platfor msize | 1.2*0.8M | |||||||
Working radius | 5.5M | 6.5M | 7.8M | 8.5M | 10.5M | 11M | 11M | 11M |
Net Weight | 1950KG | 2100KG | 2150KG | 2150KG | 2350KG | 3800KG | 4500KG | 5000KG |
Overall Width (A) | 1.7M | 1.7M | 1.7M | 1.7M | 1.7M | 1.8M | 1.8M | 1.9M |
Stowed Height (B) | 2.1M | 2.1M | 2.1M | 2.1M | 2.2M | 2.25M | 2.25M | 2.25M |
Overall Length (C) | 6.3M | 7.3M | 5.8M | 6.65M | 6.8M | 7.6M | 6.9M | 6.9M |
Length After Folding Tractor (D) | 5.2M | 6.2M | 4.7M | 5.55M | 5.7M | 6.5M | 5.8M | 5.8M |
Wind Resistance Level | ≦5 | |||||||
Rotation | 359 degree (customize with 360d egree) | 360 degree | ||||||
20’/40’Container Loading Quantity | 1set/3sets | 1set/3sets | 1set/3sets | 1set/3sets | 1set/3sets | 1set/2sets | 1set/2sets | 1set/2sets |
