Jinan PLK Machinery Co.,Ltd is one of the most reliable manufacturers and suppliers of all terrain scissor lift in China. Please feel free to buy high quality all terrain scissor lift at competitive price from our factory. Contact us for more details.
All Terrain Scissor Lift
It is one kind of self propelled scissor lift. It can reach the lifting height of 6m 8m 10m and 12m, with rated load capacity 230kg.
Motor drive supply all power for moving and lifting. There are two electric motors. One is driving motor and the other is lifting motor.
It is famous for its high efficient performance, very low failure rate and sensitive speed adjust ability. This all terrain scissor lift excels in indoor and outdoor construction, maintenance and installation applications on firm, level surfaces.
|
Model No. |
GTJZ06A |
GTJZ06B |
GTJZ08A |
GTJZ08B |
GTJZ10B |
GTJZ12B |
|
Max.working height(m) |
8 |
10 |
12 |
14 |
||
|
Max.platform height(m) |
6 |
8 |
10 |
12 |
||
|
Lifting capacity(kg) |
230 |
230 |
230 |
230 |
||
|
Extended platform capacity(kg) |
113 |
113 |
113 |
113 |
||
|
Platform size(m) |
2.26*0.81*1.1 |
2.26*1.13*1.1 |
2.26*0.81*1.1 |
2.26*1.13*1.1 |
2.26*1.13*1.1 |
2.26*1.13*1.1 |
|
Overall size-guardrail unfolding(m) |
2.48*0.81*2.21 |
2.48*1.17*2.21 |
2.48*0.81*2.34 |
2.48*1.17*2.34 |
2.48*1.17*2.47 |
2.48*1.17*2.6 |
|
Overall size-guardrail removed(m) |
2.48*0.81*1.76 |
2.48*1.17*1.76 |
2.48*0.81*1.89 |
2.48*1.17*1.89 |
2.48*1.17*2.02 |
2.48*1.17*2.15 |
|
Extended platform size(m) |
0.9 |
0.9 |
0.9 |
0.9 |
||
|
Ground clearance(m) |
0.1/0.02 |
0.1/0.02 |
0.1/0.02 |
0.1/0.02 |
||
|
Wheel base(m) |
1.92 |
1.92 |
1.92 |
1.92 |
||
|
Minimum turn radius-inner wheel |
0 |
0 |
0 |
0 |
||
|
Minimum turn radius-outer wheel(m) |
2.1 |
2.2 |
2.1 |
2.2 |
2.2 |
2.2 |
|
Driving motor(v/kw) |
2*24/0.75 |
2*24/0.75 |
2*24/0.75 |
2*24/0.75 |
||
|
Lifting Motor(v/kw) |
24/1.5 |
24/1.5 |
24/2.2 |
24/2.2 |
||
|
Lifting speed(m/min) |
4 |
4 |
4 |
4 |
||
|
Running speed-folding(km/h) |
4 |
4 |
4 |
4 |
||
|
Running speed-rising |
0 |
0 |
0 |
0 |
||
|
Battery(v/ah) |
4*6/180 |
4*6/180 |
4*6/180 |
4*6/180 |
||
|
charger(v/a) |
24/25 |
24/25 |
24/25 |
24/25 |
||
|
Maximum climbing ability |
25% |
25% |
25% |
25% |
||
|
Maximum working allowable angle |
2°/3° |
1.5°/3° |
2°/3° |
2°/3° |
1.5°/3° |
|
|
Net Weight(kg) |
1985 |
2300 |
2100 |
2500 |
2700 |
2900 |
