Jinan PLK Machinery Co.,Ltd is one of the most reliable manufacturers and suppliers of trolley vacuum glass transporter in China. Please feel free to buy high quality trolley vacuum glass transporter at competitive price from our factory. Contact us for more details.
The glass suction cup consists of two control systems (i.e. the suction cups are arranged in two rows). The finished type of suction cup (arrangement of suction cup types) controls the height of the car and the rotation of glass, marble and other flat objects. During operation, the turnover plate can be adsorbed and lifted by controlling the suction cup.
It has the functions of electric front and back walking, electro-hydraulic lifting, suction guarantee system, electric turnover and so on.
1. Suction cup suction guarantee system. If one set of suction cup leaks, the other set of suction cup can also suck goods to ensure that the vehicle can suck and lift the flap during normal operation.
2. Small appearance; Easy to use elevator. Ingenious design; The multi-function keys are centralized on the control handle.
3. Easy to move; Electric walking, electronic stepless speed regulation, stable walking, high-power driving motor to ensure the safety of glass handling.
4. Convenient charging, equipped with intelligent charger, which can provide power at any time.
Hot Tags: trolley vacuum glass transporter, China, suppliers, factory, price, Vacuum Lifter Glass, Mobile Glass Lifter, Glass Lifter Machine, Electric Glass Lifter, Others, Glass Lifting Equipment
|
Model Type |
GL-LD-350 |
GL-LD-600 |
GL-LD-800 |
|
|
Load Capacity |
350kg (arm retract) |
600kg (retract) |
800kg (retract) |
|
|
175kg (extend) |
300kg (extend) |
400kg (extend) |
||
|
Lifting Height |
3500mm |
3650mm |
5000mm |
|
|
QTY of Suction Cap |
4pcs |
6pcs |
8pcs |
|
|
Rubber Suction Cap |
Ø300mm |
Ø300mm |
Ø300mm |
|
|
Maintenance-free Battery |
2x12V/100AH |
2x12V/120AH |
2x12V/120AH |
|
|
Battery Charger |
Smart Charger |
Smart Charger |
Smart Charger |
|
|
Drive motor |
24V/600W |
24V/900W |
24V/1200W |
|
|
Lifting Motor |
24V/2000W/5L |
24V/2000W/5L |
24V/2000W/12L |
|
|
Front Wheel |
Ø310x100mm |
Ø375x110mm |
Ø400x150mm |
|
|
Driving Wheel |
Ø250x80mm |
Ø310x100mm |
Ø300x125mm |
|
|
N.W/G.W |
780/820kg |
1200/1250kg |
1600/1700kg |
|
|
Packing Size |
Wooden carton: 3150x1100x1860mm. (1x20GP Loading Qty: 5sets) |
|||
|
Movement |
Automatic (4kinds) |
1. Pad frame vertical up/down 180°automatic |
||
|
2. Boom in/out 610/760mm automatic |
||||
|
3. Powered arm up/down automatic |
||||
|
4. Lateral side shift 100mm automatic |
||||
|
Manual (2kinds) |
5. Pad frame tilt left/right 90° manual (Pls look at Optional 1. automatic turn lift/right) |
|||
|
6. Pad frame rotation 360°manual (Pls look at Optional 2. automatic rotation 360°) |
||||
|
Usages |
Special design for handling difference kind of heavy plate, such as steel, glass, granite, marble and so forth, with different materials of vacuum suction caps. |
|||
