Jinan PLK Machinery Co.,Ltd is one of the most reliable manufacturers and suppliers of mobile lift tables in China. Please feel free to buy high quality mobile lift tables at competitive price from our factory. Contact us for more details.
Mobile Lift Tables
They are the mini and smart mobile hydraulic scissor lift. They can lift 3m 300kg and 3.9m 240kg with small size and light weight.
They are moved manually and lifted electrically. Electric power means clean, quiet, fume-free operation for indoors or outdoor. With battery chargers built in, the sizes are very small, so they can fit through a standard doorway, even with the guardrails in position.
With manually propelled, the mobile lift tables are used where they can be pushed to the narrow work areas. The ultra-compact and lightweight is well suited to extremely narrow floor space and where access to the aerial work area is only available through a narrow entrance. So they are famous as the smart "mini" scissor lifts.
|
Model Type |
SJY3.0 |
SJY3.9 |
|
Max.Platform Height(MM) |
3000 |
3900 |
|
Min.Platform Height(MM) |
630 |
700 |
|
Platform Size(MM) |
1170×600 |
1170*600 |
|
Rated Capacity(KG) |
300 |
240 |
|
Lifting/Descent time(S) |
33/30 |
40/30 |
|
Lifting Motor(V/KW) |
12/0.8 |
|
|
Battery Charger(V/A) |
12/15 |
|
|
Overall Size Without Guardrail (MM) |
1300*740*1100 |
|
|
Overall Height with Guardrail (MM) |
1650 |
1700 |
|
Overall Net Weight(KG) |
360 |
420 |
