Jinan PLK Machinery Co.,Ltd is one of the most reliable manufacturers and suppliers of heavy duty scissor lift table in China. Please feel free to buy high quality heavy duty scissor lift table at competitive price from our factory. Contact us for more details.
Heavy Duty Scissor Lift Table
It is customized for the large goods with heavy load capacity, such as 10 ton, 20 ton even to 100 ton.
The lift table usually have the big platform size and lower height, because its heavy capacity.
It is usually used for factory, ship dock and wooden factory to lifting boat or wooden.
Hot Tags: heavy duty scissor lift table, China, suppliers, factory, price, Stage Scissor Lift, Small Lift Tables, Electric Table Lift, Heavy Duty Scissor Lift Table, Hydraulic Lift Table, Lift Table
|
Model |
Max. Platform Height(mm) |
Platform Size(mm) |
Self Height (mm) |
Motor (KW) |
Net weight (KG) |
|
1000Kg Load Capacity Standard Scissor Lift |
|||||
|
HW1001 |
1000 |
1300×820 |
205 |
1.1 |
160 |
|
HW1002 |
1000 |
1600×1000 |
205 |
1.1 |
186 |
|
HW1003 |
1300 |
1700×850 |
240 |
1.1 |
200 |
|
HW1004 |
1300 |
1700×1000 |
240 |
1.1 |
210 |
|
HW1005 |
1300 |
2000×850 |
240 |
1.1 |
212 |
|
HW1006 |
1300 |
2000×1000 |
240 |
1.1 |
223 |
|
HW1007 |
1300 |
1700×1500 |
240 |
1.1 |
365 |
|
HW1008 |
1300 |
2000×1700 |
240 |
1.1 |
430 |
|
2000Kg Load Capacity Standard Scissor Lift |
|||||
|
HW2001 |
1000 |
1300×850 |
230 |
1.5 |
235 |
|
HW2002 |
1050 |
1600×1000 |
230 |
1.5 |
268 |
|
HW2003 |
1300 |
1700×850 |
250 |
2.2 |
289 |
|
HW2004 |
1300 |
1700×1000 |
250 |
2.2 |
300 |
|
HW2005 |
1300 |
2000×850 |
250 |
2.2 |
300 |
|
HW2006 |
1300 |
2000×1000 |
250 |
2.2 |
315 |
|
HW2007 |
1400 |
1700×1500 |
250 |
2.2 |
415 |
|
HW2008 |
1400 |
2000×1800 |
250 |
2.2 |
500 |
|
4000Kg Load Capacity Standard Scissor Lift |
|||||
|
HW4001 |
1050 |
1700×1200 |
240 |
2.2 |
375 |
|
HW4002 |
1050 |
2000×1200 |
240 |
2.2 |
405 |
|
HW4003 |
1400 |
2000×1000 |
300 |
2.2 |
470 |
|
HW4004 |
1400 |
2000×1200 |
300 |
2.2 |
490 |
|
HW4005 |
1400 |
2200×1000 |
300 |
2.2 |
480 |
|
HW4006 |
1400 |
2200×1200 |
300 |
2.2 |
505 |
|
HW4007 |
1300 |
1700×1500 |
350 |
2.2 |
570 |
|
HW4008 |
1300 |
2200×1800 |
350 |
2.2 |
655 |
